Removing your Euro Cylinder from the door
Please choose from the following Euro Cylinder types. Advice will then be given on removing and correctly measuring your Euro cylinder. If you do not have a key to your Euro Cylinder then you may need to consult a locksmith.
Step 1
Measuring your Euro Cylinder
There are two methods for measuring Euro Cylinders and we list the measurements for both on this site.
We do, however, strongly recommend using method 1 as this is the most reliable.
Undo and remove the cylinder screw. This is located on the lock plate on the edge of the door. Sometimes the screw head is hidden behind this plate. Carefully remove plate to reveal screw
Step 2
Insert the key into the Euro Cylinder. Gently pull on the key whilst turning to the left or right Continue pulling until the Euro Cylinder is free of the door. Sometimes it may help to loosen the door handles if the cylinder is a tight fit
Carefully measure your Euro Cylinder as detailed below. Identify and order your replacement
Step 3
Method 1
Method 2
40mm
30mm
10mm
35mm
45mm
Method 1 involves measuring the Euro Cylinder in three parts, the first cylinder
section, the centre “cam”, and the last cylinder section. Always measure the shortest
cylinder section first.
When you have your measurements note which side the thumbturn
is fitted.
Be careful. Cylinders with the same measurements can have thumbturn’s on
different sides! This side is shown by the letter “T” in our list below.
Method 2 involves measuring the Euro Cylinder in two parts, each cylinder section
is measured to the centre of the “cam” or fixing hole. As with method one, always
measure the shortest side first
When you have your measurements note which side the
thumbturn is fitted.
Be careful. Cylinders with the same measurements can have thumbturn’s
on different sides! This side is shown by the letter “T” in our list below
Example: 30mm + 10mm + 40mm
The cylinder required would be 30-10-40T. The T indicates
the side of the thumbturn.
A cylinder of the same size, but with the thumbturn on
the other end would be listed as :
T30-10-40. Be Careful!
Buying your Euro Cylinder
Now you have discovered the correct measurements for your Euro cylinder. Please choose the correct product from the list below
T25-10-25 Or T30/30
T30-10-30 Or T35/35
T30-10-40 Or T35/45
30-10-40T Or 35/45T
T30-10-45 Or T35/50
T30-10-50 Or T35/55
30-10-50T Or 35/55
T35-10-35 Or T40/40
T35-10-40 Or T40/45
35-10-40T Or 40/45T
T35-10-45 Or T40/50
35-10-45T Or 40/50T
T35-10-50 Or T40/55
35-10-50T Or 40/55T
T35-10-55 Or T40/60
35-10-55T Or 40/60T
T40-10-40 Or T45/45
T40-10-45 Or T45/50
T40-10-50 Or T45/55
T45-10-45 Or T50/50
Silver
Gold
Cylinder Size
Can’t find the cylinder you’re looking for? Some unusual sizes may be available to order. Please call us for details on: 08456 123 878
Jump To
List Of
Products
£7.25
£7.95
£8.50
£8.75
£9.25
£8.50
£8.75
£9.25
£9.25
£9.25
£12.25
£12.25
£12.25
£11.95
£12.50
“T” Indicates side of thumbturn. Check Carefully!
Example: 35mm + 45mm
The cylinder required would be 35/45T. The T indicates the side
of the thumbturn.
A cylinder of the same size, but with the thumbturn on the other
end would be listed as :
T35/45. Be Careful!
£7.25
£7.95
£8.50
£8.75
£9.25
£9.25
£8.50
£8.75
£9.25
£9.25
£9.25
£12.25
£12.25
£12.25
£11.95
£12.50
Silver
Gold
£14.50
£15.25
£15.75
£15.95
£16.25
£16.25
£15.75
£16.25
£16.25
£16.75
£16.75
£16.25
£16.75
£16.75
£14.50
£15.25
£15.75
£15.95
£16.25
£16.25
£15.75
£16.25
£16.25
£16.75
£16.75
£16.25
£16.75
£16.75
Specialist Thumbturn Euro Cylinders
“Blind” Thumbturn Half Euro Cylinder.
Single sided Euro Cylinder operated by thumbturn
only.
Cylinder does not use keys
T30-10-05 Or T35/10
£12.70
Gold
Silver
Cylinder Size
High Quality 6 Pin Euro Cylinders
Resistant to Picking, Drilling & Bumping. Snap-safe
& Conforming to BS EN1303
Standard Quality Euro Cylinders
Good Quality, Reliable & Great Value 5 Pin Cylinders.
All Prices Shown Excluding VAT And Delivery Charges
